Test Methods and Specifications
Wire Rope Safety Barrier
- Publication no: ATS-4220-26
- Published: 14 January 2026
- Edition: 1.0
- PDF (free) Download
Austroads Technical Specification ATS 4220 sets out the requirements for the supply and installation of wire rope safety barrier (WRSB) systems.
ATS 4220 may be used for new installations and for the repair or replacement of existing WRSB systems.
The following are excluded from this Specification:
- design of the WRSB system;
- steel rail safety barrier systems (refer to ATS 4210);
- concrete safety barriers (refer to ATS 4230);
- temporary safety barriers used during the construction of roadworks or bridgeworks; and
- balustrades, pedestrian fences or other fences adjacent to roads.
This specification is also available as a Word document.
- 1. Scope
- 2. Referenced Documents
- 3. Definitions
- 4. Quality System Requirements
- 5. Materials and Components
- General
- Protective Treatment
- Identification
- Material Handling and Storage
- Certification of Conformance
- 6. Personnel
- 7. Installation
- General
- Set Out
- Post Foundations and Anchor Blocks
- Posts
- Loading Test of Post Foundations
- Location of Posts Adjacent to Batter Hinge Points
Wire Rope - WRSB over Box Culverts and Concrete Pipes
- Stray Current Effects on WRSB
- Interface with Other Safety Barriers
- Delineators
- 8. Removal of Existing Roadside Furniture
- 9. Damage and Reinstatement
- 10. Tolerances
- 11. Completion
- General
- Certificate of Compliance
- ‘As-constructed’ and Maintenance Documentation
- Annexure A Summary of Hold Points, Witness Points and Records
- Amendment Record
