Test Methods and Specifications
Structural Steelwork – Fabrication and Erection
- Publication no: ATS-5410-25
- Published: 22 August 2025
- Edition: 3.0
- PDF (free) Download
Austroads Technical Specification ATS 5410 sets out the requirements for the construction of steelwork for bridges and gantries that:
- are designed in accordance with AS/NZS 5100.6;
- use steel complying with one or more of the material standards listed in Table 5.3; and
- use steel with a design yield stress of 690 MPa or less.
If specified in the Contract documents, it applies to other structures such as poles and roadside furniture.
ATS 5410 comprises wholly or partially the ‘construction specification’ referenced in AS/NZS 5131.
Steel fabrication, erection and modification must be carried out in accordance with:
- Steelwork Design Documentation;
- this Specification;
- any manufacturer’s instructions specifically applicable to the item concerned; and
- AS/NZS 5131.
In the event of an ambiguity or inconsistency, the above order of precedence applies.
The technical specification can also be downloaded as a Word document.
Edition 3.0 published August 2025
Throughout the document – changes made to the language to remove ambiguities and improve readability.
