Road Design
- Publication no: AGRD04A-17
- ISBN: 978-1-922382-19-1
- Published: 26 February 2021
- Edition: 3.1
- Superseded
- PDF (free) Download
Guide to Road Design Part 4A: Unsignalised and Signalised Intersections provides road designers and other practitioners with guidance on the detailed geometric design of all at-grade intersections (excluding roundabouts).
This Part contains information for the design of signalised and unsignalised intersections. Guidance is provided on intersection sight distances, including approach sight distance, safe intersection sight distance, and minimum gap sight distance. Left and right turn treatments are outlined including the incorporation of auxiliary lanes at intersections and the use and size of traffic islands.
Edition 3.1 of the Guide contains a new Figure 1.1 and minor editorial and technical changes to Sections 1.3, 2.1, 3.1, 5.2, 6.1, 8.2 and 9.2.
